| SKU | 61.102.51.APB | ||
|---|---|---|---|
| Wheel Diameter | 10 Inches | Weight Capacity | 1500 Lbs |
| Wheel Width | 2 Inches | Tread Style | Radius Tread |
| Overall Height | 11-1/8 Inches | Wheel Material | Polyurethane |
| Core Material | Aluminum | Bearing Type | Ball Bearing |
| Caster Type | Rigid | Mounting Type | Top Plate |
| Top Plate | 4-1/2 Inches x 6-1/4 Inches | Axle Type | Solid Axle |
| Top Plate Holes | 2-7/16 inches – 3-3/8 inches x 4-15/16 inches – 5-1/4 inches | Fork Finish | Zinc Plated |
Overview
This industrial rigid caster has a polyurethane caster wheel with a diameter of 10 inches and is ideal for heavy duty industrial applications. This fixed caster is cost effective and overall a fantastic economical choice. The 61.102.51.APB features a larger top plate (indicated by "51" in the SKU) for enhanced stability and mounting options, making it ideal for applications requiring a more robust connection to the equipment. Ball bearings are sealed and pre-lubricated, providing better ergonomics and less maintenance.
Benefits
The main benefit of the rigid caster is that it provides directional stability and higher load capacity compared to swivel casters. This non-swivel caster is typically used in tandem with our kingpinless swivel casters (casters that begin with "60"). Most carts use 2 swivel and 2 rigid casters for optimal maneuverability and directional stability.
The larger top plate on this model provides additional mounting surface area, which distributes the load more evenly and creates a more secure connection to equipment. This is particularly beneficial for applications with higher load requirements or where vibration might be a concern.
The polyurethane wheels have their own benefits, such as superior floor protection, longer service life, low rolling resistance, high dynamic load capacity and high tear resistance. Check out our blog about 5 reasons to get polyurethane wheels on your casters to learn more.
The larger 10-inch wheel diameter provides significant advantages including even smoother operation over uneven surfaces, greatly reduced rolling resistance, and the ability to easily overcome obstacles on the floor. This makes these casters particularly suitable for applications where equipment needs to be moved over rough surfaces, expansion joints, door thresholds, or outdoor areas.
Applications
Applications for large diameter polyurethane rigid casters with larger top plates include industrial manufacturing, heavy material handling, large platform trucks, machinery movers, and equipment that needs to be regularly relocated. The larger mounting plate makes this caster particularly suitable for equipment that experiences significant lateral forces or carries heavy or top-heavy loads.
Due to the high load capacity and large wheel size, these casters are ideal for moving heavy equipment across varied floor conditions. Polyurethane caster wheels work exceptionally well in Woodworking, Aerospace, Automotive and Food Processing industries where both floor protection and durability are required. The polyurethane wheels with their radius tread design provide excellent floor protection and maneuverability across a variety of surfaces. Click here to learn more about our polyurethane wheels.
This rigid caster is best used in combination with swivel casters for optimal mobility. If your business requires additional heavy duty caster solutions, you will want to review our Heavy Duty Kingpinless Casters category.
Read our case study on Kinpinless Casters to see how a solar car club at Iowa State University utilized Barron casters to streamline their processes.
Selection Assistance
Not sure which caster would work best for your application? Check out this blog post to learn how to select the best caster for your application. For further assistance, we have a whole team of caster experts dedicated to find the perfect caster for your business that can help improve ergonomics and save your company money. Fill out the form below and a Barron caster representative will be in touch soon!
