14 Gauge – 90 Gallon Flammable Cabinet With Manual Closing Doors – 43 in. W x 34 in. D x 70 in. H

FAQs

Is this the most cost-effective way to store 90 gallons of flammable liquids in a single cabinet?

Yes. The manual-closing version delivers the same 90-gallon capacity, 14-gauge all-welded steel construction, and full OSHA, NFPA 30, and FM compliance as the self-closing model at a lower price. The savings come from the manual door mechanism, which does not include the automatic closure system or fusible link.

Does a manual-closing 90 gallon flammable cabinet meet the same fire codes as the self-closing version?

Yes. Both models meet NFPA 30 and OSHA standards and are FM approved. Double-wall construction with a 1.5-inch insulating air space, flash arrestor vents, a leakproof sump, a static grounding connection, and a non-sparking 3-point locking mechanism are all included. The manual-close model meets every structural and containment requirement that the self-closing version does.

When should I choose manual-closing doors over self-closing for a 90 gallon fire cabinet?

Manual doors are a good choice for controlled environments where trained personnel manage the cabinet and traffic around it is low. The doors open to a full 180 degrees for easy bulk loading and self-latch when pushed shut. For high-traffic areas, shared workspaces, or locations where doors may be left open unattended, the self-closing model provides an additional level of passive fire protection.

How does a 90 gallon cabinet help with NFPA storage limits?

NFPA 30 permits up to 120 gallons of Class I, II, and IIIA liquids in approved safety cabinets within a single fire area. A single 90-gallon unit covers 75 percent of that allowance, reducing the number of cabinets needed and simplifying compliance audits and inspections.

What shelving comes with this flammable material cabinet?

Three galvanized steel shelves are included, each rated at 600 pounds. The sloped shelf design directs spills toward the cabinet's rear sump. Shelves adjust without tools, and magnetic labels help your team identify stored chemicals quickly during daily operations or inspections.

How large are the containers that fit inside this flammable storage cabinet?

The 34-inch interior depth and 43-inch width accommodate standard 5-gallon safety cans, 2.5-gallon containers, and most common solvent and chemical bottles. The three-shelf layout provides enough vertical separation to organize containers by type, hazard class, or department without overcrowding.
