Overview
Loading and unloading pallets is a time-consuming, back-breaking job that can lead to excess worker fatigue or even injury. The PalletPal Powered Pneumatic Positioner makes this work faster, safer, and easier. When loads, weights, pallet sizes, or product dimensions vary greatly, this pneumatic positioner with total operator control is the solution. A foot control allows the operator to adjust the load to an infinite number of positions, so it is always at the most comfortable height for loading and unloading.
| SKU | PPA2-24 |
|---|---|
| Material | Steel |
| Lift Mechanism | Pneumatic |
| Load Capacity | 2000 Lbs |
| Color | Red |
| Overall Width | 43 5/8 Inches |
| Overall Length | 43 5/8 Inches |
| Raised Height | 33 7/16 Inches |
| Lowered Height | 9 1/2 Inches |
| Turntable Diameter | 43-5/8 Inches |
| Power | 80 PSI/15 CFM |
| Ship Weight | 640 lbs |
| Resources | PalletPal Brochure |
*This is not a lifting capacity. This airbag actuated machine is dedicated to pallet positioning applications. The capacity denotes the maximum weight of the fully loaded pallet that is appropriate for this model.
Features & Benefits
The PalletPal Powered Pneumatic Positioner operates on shop air. A heavy-duty airbag positions pallet loads weighing up to 2,000 lbs with as little as 80 PSI. The manual turntable allows quick and easy rotation of the load so that the operator is always working on the near side, eliminating reaching, stretching, and walking around.
Built-in fork pockets provide both ease of portability and additional stability. The turntable is specifically designed for loads that vary in weight, size, or product dimensions, allowing workers to position pallets at a comfortable working height virtually eliminating bending, reaching, and stretching when building or breaking down pallet loads.
By spinning the load, operators are always working on the near side. This eliminates the need for walking around pallets while carrying heavy loads and removes the potential for trip and fall accidents. The pneumatic design is ideal for environments where loads vary widely and are changed frequently.
Applications
The PalletPal Powered Pneumatic Positioner is ideal for a variety of industrial settings where ergonomics and worker safety are priorities:
- Manufacturing facilities
- Warehousing and distribution centers
- Shipping and receiving areas
- Production lines
- Food processing plants
- Pharmaceutical operations
- Assembly workstations
- Retail back-of-house operations
Selection Assistance
A small investment in the PalletPal Powered Pneumatic Positioner pays dividends by increasing productivity, reducing employee lost time, and creating a happier, more motivated workforce. If you have questions about which PalletPal model best suits your operation, our product specialists can help you determine the right solution for your specific application.
Fill out the form below and our product specialist will be in touch shortly to discuss how the PalletPal Powered Pneumatic Positioner can improve your operation's efficiency and ergonomics.
