Overview
The Southworth L Series CAM Lift Table uses an exclusive cam mechanism instead of a traditional scissor design to deliver extreme load capacity from a remarkably low collapsed height. Where standard scissor lifts require taller collapsed profiles to handle heavy loads, the cam design achieves capacities from 8,000 to 30,000 lbs with collapsed heights as low as 7.625 inches. All five standard models provide 36 inches of travel, raising loads to heights between 43.6 and 47.25 inches depending on capacity.
The L Series fills a specific niche in heavy industrial material handling: applications that require both extreme capacity and minimal floor‑level clearance. Standard platforms range from 30 x 60 inches to 43 x 72 inches, with maximum platform sizes reaching 72 x 96 inches on the highest‑capacity models. All models operate on 460V 3‑phase power with a 3.2 HP motor.
Features and Benefits
The cam mechanism is the defining advantage of the L Series. By replacing the scissor linkage with a rotary cam design, the lift achieves a collapsed‑height‑to‑capacity ratio that no scissor lift table can match. The L8‑36 collapses to just 7.625 inches while handling 8,000 lbs. Even the 30,000 lb L30‑36 collapses to only 11.25 inches. This makes the cam lift ideal for pit‑mounted applications, loading dock integrations, and any installation where overhead or floor‑level clearance is limited.
Heavy‑plate platforms with structural reinforcements minimize deflection under extreme loads. The wide base provides increased rigidity and stability. Southworth’s proven hydraulic system delivers smooth, controlled lifting with a 3.2 HP motor. These high capacity lifting tables are built to withstand the most demanding industrial environments with minimal ongoing maintenance.
Applications
The L Series serves applications where extreme capacity is required with minimal collapsed height. Common uses include pit‑mounted cargo handling where the platform must sit flush with the floor when lowered, loading dock integrations where height clearance below the platform is restricted, heavy die handling and press feeding where multi‑ton tooling must be positioned precisely, vehicle maintenance where heavy equipment must be raised from near‑floor level, and any industrial process that needs 8,000 to 30,000 lbs of lifting capacity from a collapsed profile under 12 inches.
Selection Assistance
All five L Series models provide 36 inches of travel. Selection depends primarily on required capacity and platform size. The L8‑36 provides the lowest collapsed height at 7.625 inches for 8,000 lb loads. The L30‑36 handles 30,000 lbs with a collapsed height of 11.25 inches. For applications that need higher travel with extreme capacity, the Southworth DL Series Heavy Duty provides up to 84 inches of travel. For standard‑duty capacities under 6,000 lbs, the Backsaver Hydraulic and LS Series are more cost‑effective. Barron Equipment can help you determine whether the cam design is the right solution. Contact our team to discuss your application.
