| SKU | 70.63.51.NYB | 2D Drawing | 2D Drawing |
|---|---|---|---|
| Wheel Diameter | 6 Inches | Weight Capacity | 5400 lbs |
| Wheel Width | 3 Inches | Tread Style | Flat Tread |
| Overall Height | 7-1/2 Inches | Wheel Material | Nylon |
| Core Material | Nylon | Bearing Type | Ball Bearing |
| Caster Type | Swivel | Mounting Type | Top Plate |
| Top Plate | 4-1/2 Inches x 6-1/2 Inches | Axle Type | Solid Axle |
| Top Plate Holes | 2-7/16 Inches - 3-3/8 Inches x 4-15/16 Inches - 5-1/4 Inches | Fork Finish | Zinc Plated |
Overview
This kingpinless swivel caster has a nylon caster wheel with a diameter of 6 inches and is ideal for heavy duty industrial applications. This swivel caster has more benefits and better overall ergonomics than the standard industrial caster.
Benefits
The main benefit of the kingpinless series casters is that they eliminate the use of the kingpin which allows for longer use, better ergonomics and more efficiency. In addition to benefits of the overall kingpinless caster category, nylon wheels have their own benefits such as being resistant to moisture and chemicals and they are well suited for corrosive environments or applications where sanitary conditions are important.
Applications
Applications for nylon wheel kingpinless casters include industrial manufacturing and warehousing. You'll see casters with nylon wheels on waste bins, platform trucks, job boxes and in bakeries, woodworking facilities and in the aerospace, automotive and food processing industries. Click here to learn more about our nylon wheels.
A locking swivel caster is also available in this series for added safety and stability. Look for part numbers that end in "FCB," "BIB," "DSL," "TB," and "IS" which stand for "Face Contact Brake," "Built in Brake," "Demountable Swivel Lock," "Top Lock Brake," and "Ideal Stop Brake" respectively. For more information about our caster braking options, check out our blog post about the variety of brakes we offer - Braking Ground: A Comprehensive Guide to Diverse Industrial Caster Brake Types.
If your business requires a heavy duty swivel caster solution, you will want to review our Heavy Duty Kingpinless Casters category.
