Overview
This hydraulic scissor lift table provides 2,000 lbs of lifting capacity with 36 in. of vertical travel, raising loads from 7.25 in. to 43.25 in. Available in two platform sizes — 24 in. x 48 in. and 48 in. x 72 in. — it fits a wide range of material handling tasks across manufacturing, shipping, and assembly environments. The hydraulic power unit delivers smooth, controlled lifting and lowering, supporting consistent performance throughout every shift.
Often referred to as a "backsaver" table, this scissor lift table helps workers raise materials to a safe and comfortable height instead of bending, stooping, or lifting loads by hand. The result is fewer injuries, less fatigue, and steadier productivity over the course of the day. Whether used at a loading dock, production line, or repair area, this lift table provides dependable operation and ergonomic positioning for a wide range of industrial workflows.
Benefits
Repetitive manual lifting is one of the leading causes of workplace injuries in industrial settings. This hydraulic lift table addresses that risk directly by raising loads to the right working height, keeping operators in a neutral posture and reducing the strain that leads to back injuries and lost time. The smooth, predictable motion of the power unit means workers can position loads precisely without sudden drops or jerky movement.
Heavy-duty torque tubes minimize platform twisting and deflection, keeping the surface stable even under full load. Contoured scissor legs provide extra strength at each pivot point while maintaining a ground-level collapsed height of 7.25 in. for easy loading from pallet jacks and hand trucks. Pressure-compensated flow control allows operators to adjust the lowering speed, giving them more control during precise work positioning tasks.
Built-in safety features include maintenance props that prevent accidental lowering during servicing and a tell-tale hydraulic return line that gives early visual warning when cylinder repacking is needed. Lubricated-for-life bushings at every pivot point reduce ongoing maintenance, and heavy-duty hoses with burst strength rated at 600% above operating pressure provide an extra margin of reliability. These features work together to keep the lift table running day after day with minimal downtime.
| Model Number | Load Capacity (lbs.) | Raised Height (in.) | Lowered Height (in.) | Standard Platform Size (in.) | Link to Page |
|---|---|---|---|---|---|
| LS2-24 | 2000 | 31.25 | 7.25 | 24 x 36 | Link |
| LS4-24 | 4000 | 31.25 | 7.25 | 24 x 36 | Link |
| LS2-36 | 2000 | 43.25 | 7.25 | 24 x 48 | Link |
| LS4-36 | 4000 | 43.25 | 7.25 | 24 x 48 | Link |
| LS4-36WFMTT | 3500 | 43.25 | 7.25 | 36 x 48 | Link |
| LS2-48 | 2000 | 55.25 | 7.25 | 24 x 64 | Link |
Applications
This scissor lift table is used across a wide range of industrial settings where workers need to raise, lower, or position heavy materials throughout the day. Common applications include machine feeding in manufacturing cells, work positioning on assembly lines, pallet loading and unloading in shipping and receiving areas, and parts inspection in quality control stations. Auto repair shops and maintenance departments also benefit from the ability to raise heavy components to a comfortable working height.
The 24 in. x 48 in. platform accommodates standard pallets and typical industrial loads. For facilities handling larger or wider materials — sheet goods, oversized assemblies, or bulky containers — the 48 in. x 72 in. platform provides significantly more surface area. Both options share the same low 7.25 in. lowered height, allowing ground-level loading and easy integration with pallet jacks, carts, and hand trucks. Because the table raises to 43.25 in., most standing workers can operate at a comfortable height that reduces bending and reaching throughout the shift.
Maintenance
This lift table is designed for low maintenance and long-lasting performance. Sealed lubricated-for-life bushings at every pivot point eliminate the need for routine greasing. The tell-tale hydraulic return line provides a clear visual signal when cylinder maintenance is approaching, so service can be scheduled before a problem develops.
Routine upkeep includes periodic visual checks of the hydraulic lines, scissor arms, platform surface, and rollers. Hydraulic fluid should be cycled out every six months to maintain consistent lifting performance. The built-in maintenance props allow safe access to the underside of the table during any service work. These simple steps help extend the life of the lift table and prevent unplanned downtime in facilities that depend on reliable daily operation.
Selection Assistance
Choosing the right hydraulic lift table starts with understanding the weight of the materials you handle, the platform size you need, and how the table will be used day to day. This 2,000 lb model covers a wide range of typical industrial loads. For heavier applications above 2,000 lbs, the LS4-36 offers a 4,000 lb capacity on the same platform sizes. For smaller footprints, the LS2-24 provides the same 2,000 lb capacity on a compact 24 in. x 36 in. platform, and the LS2-48 extends to a 24 in. x 64 in. surface for long or oversized materials.
Additional configuration options include conveyor tops, turntables, fork pockets, bellows skirting, and pit mounting. If your process requires load rotation, the LS4-36WFMTT adds a flush-mounted turntable to the lift table platform. Barron Equipment can help match the right model and options to your specific workflow. Fill out the form below and a product specialist will reach out to assist you.
